Yousef Steel stands out as a trusted manufacturer and supplier based in Riyadh, Saudi Arabia, specializing in top-notch SA 516 Grade 65 Sheets and Plates. These products are essential in boiler and pressure vessel applications, known for their remarkable durability, strength, and performance even in high-temperature environments. Crafted to adhere to rigorous industry standards, these plates boast impressive resistance to both pressure and thermal stress, making them a go-to choice for sectors like petrochemical, oil & gas, and power generation, where safety and longevity are paramount.
The composition of SA 516 Grade 65 Sheets and Plates includes carbon, manganese, phosphorus, sulfur, and silicon, which together create a robust and stable structure. They offer outstanding mechanical properties, with tensile strength ranging from 415 to 585 MPa and dependable yield strength, along with commendable notch toughness. Their excellent weldability and formability further enhance their suitability for use in pressure-containing equipment. The balanced chemistry and strength of these plates make them a reliable option for demanding industrial applications.
Grade : ASME SA 516 GR.65 Boiler and Pressure Vessel Steel Plates
Width : 1250mm-3000mm
Thickness : 3 – 200 mm/ dimensions up to 4.000 mm
Length : 3000mm-11000mm.
Production : Hot-Rolled (HR)
Heat Treatment : Rolled/Normalised/N+T/QT
| C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V |
| 0.08/0.20 | 0.4 | 0.9/1.5 | 0.03 | 0.03 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| Tensile strength (ksi) | Tensile strength (MPa) | Yield strength (ksi) | Yield strength (MPa) | Elongation in 200mm (min)(%) | Elongation in 50mm (min) (%) |
| 65-85 | 450-585 | 35 | 240 | 19 | 23 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
SA 516 Grade 65 plates and sheets have extensive applications in high-strength, pressure-bearing industries. They are most suitable for the production of boilers, pressure vessels, heat exchangers, and storage tanks for oil, gas, and petrochemical industries. Their high weldability and toughness render them as convenient for application to power plants, refineries, and ships. In addition, they find application in chemical processing equipment and nuclear reactors owing to their high resistance to aggressive environments and ruggedness. Having better notch toughness, SA 516 Grade 65 provides safety and reliability at high pressures, thus making it a first choice for severe industrial applications.
Yousef Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Riyadh, Saudi Arabia.
