Yousef Steel stands out as a reliable manufacturer and supplier based in Riyadh, Saudi Arabia, specializing in top-notch SA 515 Grade 70 Sheets and Plates. These materials are essential in the fabrication of pressure vessels and boilers, designed to thrive in high-temperature settings. With impressive strength, toughness, and durability, these plates are crafted under rigorous quality standards, ensuring they deliver reliability and a long service life. This makes them a go-to choice for industries like petrochemical, oil & gas, and power generation, where safety and performance are paramount.
The composition of SA 515 Grade 70 Sheets and Plates includes carbon, manganese, phosphorus, sulfur, and silicon, creating a balanced structure that enhances both strength and workability. They boast a high tensile strength ranging from 485 to 620 MPa, along with commendable yield strength and toughness. Additionally, these plates are known for their excellent weldability and machinability, making them easy to work with when fabricating boilers, pressure vessels, and heat exchangers. Their robust mechanical properties and chemical composition make SA 515 Grade 70 Sheets and Plates a dependable choice for pressure-containing applications.
| Specifications | ASTM A515 Gr. 60 / ASME A515 Grade 60 | |
| Thickness |
| |
| Length | 3000 mm – 8000 mm | |
| Width | 1500-3500mm | |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange) | |
| Finish | Cold rolled sheet (CR), Hot rolled plate (HR) | |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | C | Mn | P | S | Si |
|---|---|---|---|---|---|
| A515 Grade 70 | 0.30-0.35 | 1.30 max | 0.035 max | 0.035 max | 0.13-0.45 |
| Grade | Yield | Tensile | Thickness | Elongation |
|---|---|---|---|---|
| A515 Grade 70 | MPa -551 min | MPa – 485-620 | 50-200mm | 17-21% |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
These sheets and plates are commonly utilized in constructing boilers, storage tanks, heat exchangers, and pressure vessels that operate under high temperatures. They are particularly favored in refineries, chemical plants, and power stations due to their resilience against thermal stress and internal pressure. With their unique blend of strength, durability, and ease of fabrication, SA 515 Grade 70 Sheets and Plates ensure long-lasting performance and safety, making them a vital material for heavy-duty industrial applications.
