Yousef Steel, a well-respected manufacturer and supplier based in Riyadh, Saudi Arabia, specializes in high-quality J356 tubing that’s designed to meet the rigorous demands of various industrial applications. Crafted with precision and in line with international standards, J356 tubing is celebrated for its remarkable strength, durability, and reliability. It’s built to endure high pressure, stress, and tough environments, making it a go-to choice across a range of sectors. Thanks to cutting-edge production technology, stringent quality control, and prompt delivery, Yousef Steel guarantees that J356 tubing consistently performs well and has a long service life for clients in construction, engineering, and energy industries.
The production of J356 tubing involves a carefully balanced mix of carbon, manganese, phosphorus, sulfur, and a few alloying elements, which together ensure its toughness and durability. It boasts impressive mechanical properties, including high tensile and yield strength, good elongation, and outstanding impact resistance. Plus, the tubing is easy to machine, weld, and form, making it suitable for a variety of fabrication processes. Its ability to resist stress, pressure, and wear ensures dependable performance, while its structural integrity makes it perfect for both standard and heavy-duty applications.
| Grade: | ASME/ASTM SA179, SA192, SA210, SA178, SA214, API 5L |
|---|---|
| Size: | 1/8” NB TO 24” NB Sch 40/80/160/XXS |
| Form | Round, Square, Rectangular, Coil, U Tube, |
| Length | Single Random, Double Random & Required Length |
| End | Plain End, Bevelled End |
| Type | Seamless / ERW / Welded |
| Certification For Carbon | Mill Test Certificate as per EN 10204 / 3.2B |
| General Requirements | ASTM A 530/A 530M |
| Dimensional Tolerances | ANSI B 36.10 |
| OD Range | 1.250″ – 6.000″ (30-150mm) |
| Wall Range | 0.095″ – 1.000″ (.2.5-25mm) |
| CHEMICAL REQUIREMENTS | ||
| Element | Cast or Heat Analysis: Weight % | |
| J356 | J356 Type-A | |
| Carbon | 0.06 Min/0.18 Max | 0.02 Min/0.18 Max |
| Manganese | 0.30 Min/0.60 Max | 0.10 Min/0.60 Max |
| Phosphorus | 0.04 Max | 0.04 Max |
| Sulfur | 0.06 Max | 0.05 Max |
| MECHANICAL PROPERTIES | |
| Properties | Values |
| Yield Strength (Min) | 25,000 PSI |
| Tensile Strength (Min.) | 45,000 PSI |
| Elongation in 2” (Min) | 35% a |
| Hardness (Rockwell B)(Max) | 65 b |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| TUBING WALL THICKNESS TOLERANCES | |||
|---|---|---|---|
| Nominal Wall Thickness (Inches) |
Nominal Tube OD Through 1” (+/- Inches) |
Nominal Tube OD Over 1” Through 2” (+/- Inches) |
Nominal Tube OD Over 2” Through 4” (+/- Inches) |
| .028 (22 Ga) | .002/.003 | .003/.003 | .003/.003 |
| .035 (20 Ga) | .002/.004 | .002/.004 | .002/.004 |
| .042 (19 Ga) | .002/.004 | .002/.004 | .002/.005 |
| .049 (18 Ga) | .004/.005 | .003/.005 | .004/.008 |
| .058 (17 Ga) | .006/.006 | .004/.008 | .004/.008 |
| .065 (16 Ga) | .006/.006 | .004/.008 | .004/.008 |
| .072 (15 Ga) | .006/.010 | .006/.010 | .006/.010 |
| .083 (14 Ga) | .006/.010 | .006/.010 | .006/.010 |
| .095 (13 Ga) | .006/.010 | .006/.010 | .006/.010 |
| .100 | .006/.010 | .006/.010 | .006/.010 |
| .109 (12 Ga) | .006/.010 | .006/.010 | .006/.010 |
| .118 | .006/.010 | .006/.010 | .006/.010 |
| .120 (11 Ga) | .006/.010 | .006/.010 | .006/.010 |
| .134 (10 Ga) | .006/.010 | .006/.010 | .006/.010 |
| .148 (9 Ga) | — | .007/.001 | .007/.011 |
| .156 (5/32) | — | .007/.011 | .007/.011 |
| .165 (8 Ga) | — | .007/.011 | .007/.011 |
| .180 (7 Ga) | — | .007/.011 | .007/.011 |
| .197 | — | .008/0.12 | .008/0.12 |
| .203 (6 Ga) | — | .008/0.12 | .008/0.12 |
| .219 (7/32) | — | .008/.012 | .008/.012 |
| .236 | — | .014/.018 | .014/.018 |
| .238 (4 Ga) | — | .014/.018 | .014/.018 |
| .259 (3 Ga) | — | .014/.020 | .014/.020 |
J356 tubing is widely utilized in industries where strength and reliability are paramount. It finds applications in automotive systems, hydraulic lines, fuel injection systems, and mechanical engineering projects. Its capacity to handle high pressure makes it ideal for fluid conveyance systems, boilers, and heat exchangers. Additionally, it’s used in construction equipment, agricultural machinery, and general manufacturing. With its durability, versatility, and high-performance characteristics, J356 tubing is essential for enhancing operational safety, efficiency, and longevity across various industrial applications.
