Yousef Steel stands out as a trusted manufacturer and supplier based in Riyadh, Saudi Arabia, specializing in top-notch Carbon Steel F48 Forged Fittings that are crafted for strength, durability, and precision. These fittings are expertly designed to ensure secure, leak-proof, and long-lasting connections in high-pressure and high-temperature piping systems. Renowned for their toughness and versatility, Carbon Steel F48 Forged Fittings find their place in various industries, including oil & gas, petrochemical, power generation, shipbuilding, and construction. With a commitment to strict quality standards, Yousef Steel guarantees consistent performance and reliability in every fitting they deliver.
The manufacturing process of Carbon Steel F48 Forged Fittings involves high-quality carbon steel, carefully controlled for carbon, manganese, and silicon content, resulting in impressive tensile strength, yield strength, and hardness. They boast excellent impact resistance, durability under stress, and outstanding mechanical performance. Their strong weldability and machinability make them perfect for critical industrial applications, while proper finishing boosts their resistance to corrosion and wear.
Standard : ASTM A694 / ASME SA 694
Dimensions : ASME/ANSI 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8″ NB to 4″ NB
Type : Socketweld Fittings, Screwed-Threaded Fittings (NPT or PT Type)
Rating Pressure : Threaded End – 2000 /3000/ 6000 LBS. Socket-weld End – 3000 / 6000/ 9000 LBS.
| Grade | C | Si | Mn | P | S | Mo | Ni | Cr | Cu | V | Nb |
| F48 | 0.06-0.10 | 0.20-0.40 | 1.10-1.40 | ≤ 0.020 | ≤ 0.010 | 1.20-1.70 | 0.20-0.40 | ≤ 0.30 | ≤ 0.25 | 0.02-0.06 | – |
| Grade | Yield Strength, Min (KSI ) | Tensile Strength, Min (KSI) |
| F48 | 70 | 82 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| ASME B16.11 | Factory-Made Wrought Socketweld Fittings | CS F48 Forged Screwed Elbows, Street Elbow, Carbon Steel F48 Screwed Unequal Tee, Steel Straight Tee, Carbon Steel F48 Reducing Coupling, Carbon Steel F48 Hex Plug, Forged Straight Tees, Socket Weld Pipe Cap, Forged Pipe Cap, Equal Crossess, CS F48 Threaded Bushing, Carbon Steel F48 Screwed Caps, Swedge Nipples |
| MSS-SP-79 | standard Practice covers ratings, tolerances, finish, dimensions, marking and material requirements for socket-welding | Carbon Steel F48 Barrel Nipples, CS F48 Forged Threaded Boss, Carbon Steel F48 Forged Hex Head Bull Plugs |
| MSS-SP-83 | Forged and Fabricated Socket-Welding Fittings for Low Pressure, Corrosion Resistant Applications | Carbon Steel F48 High Quality Socket weld 90° Elbow, Straight and Reducing-on-the-Tees, Forged 45° Short Radius Elbow, CS F48 caps, 3000LB Socket Weld Cross |
| MSS-SP-95 | Integrally Reinforced Forged Fittings – Socket Welding, Threaded, and Buttwelding Ends | CS F48 Socket weld Long Radius 90 Degree Elbows, Reducing Nipple, Socketweld Bushing, Threaded Plug, End Pipe caps, Carbon Steel F48 Coupling |
Carbon Steel Forged Fittings F48 are being extensively applied in many industries because of their high strength, corrosion resistance, and durability. These fittings find crucial applications in oil and gas, petrochemical, power generation, and chemical industries to connect pipes, valves, and pumps under high pressure and high temperatures. They are also used in HVAC systems, water treatment plants, and maritime applications. Its ability to sustain tough conditions qualifies Carbon Steel F48 Forged Fittings to be utilized in construction, refineries, and manufacturing operations. Their stable performance ensures the integrity and safety of complex piping systems in a wide range of industries.
Yousef Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Riyadh, Saudi Arabia.
