Yousef Steel is a reputable manufacturer and supplier of Carbon Steel EN 10083-2 Grade C22R Pipes, proudly based in Riyadh, Saudi Arabia. Known for their commitment to quality, Yousef Steel delivers C22R-grade pipes that adhere to the EN 10083-2 standards for heat-treatable steels. These pipes are celebrated for their outstanding machinability, good ductility, and dependable mechanical strength, making them perfect for a variety of engineering and industrial uses. Yousef Steel caters to clients in the automotive, general manufacturing, and construction industries throughout Saudi Arabia and the Middle East, ensuring consistent quality, prompt delivery, and a customer-centric approach.
The Carbon Steel EN 10083-2 Grade C22R Pipes contain about 0.18–0.24% carbon and 0.50–0.80% manganese, with low levels of sulfur and phosphorus to enhance workability and toughness. They boast a tensile strength ranging from 430–580 MPa and a yield strength of approximately 240–340 MPa. In their normalized state, the Brinell hardness falls between 110 and 160 HB. C22R is known for its excellent machinability and moderate mechanical properties, and it responds well to heat treatments like carburizing and tempering, making it suitable for light to medium-duty applications that require formability and wear resistance.
| Specification | Details |
|---|---|
| Material | EN 10083-2 Grade C22R Carbon Steel |
| Product | Seamless Pipes and Tubes |
| Carbon Content | Max 0.20% |
| Manganese Content | 0.50% – 1.40% |
| Characteristics | – Low-Cost: Cost-effective option for low-carbon steel pipes – Formability: Easy to form and shape – Surface Hardness: Not as hard as high carbon steel pipes, but can be – increased through carburizing |
| Standard | Manufactured as per EN 10083-2 specification |
| Commercial Reference | Referred to as CS (carbon steel) pipes or MS (mild steel) pipes |
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
| 0.17-0.24 | max 0.40 | 0.40-0.70 | 0.045 | 0.045 | max 0.10 | max 0.40 | max 0.40 | – | – |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
| 430 | – | – | 24 | ||
| DIN | EN | BS | NFA | ASTM | ASME |
|---|---|---|---|---|---|
| DIN 17204 Grade Cm22 | EN 10083-2 Grade C22R | – | ASTM A519 Grade 1021 | ASME SA 519 Grade 1021 | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Yousef Steel is a trusted manufacturer and supplier of high-quality Carbon Steel EN 10083-2 Grade C22R Pipe products in Riyadh, Saudi Arabia. Specializing in premium steel materials, we offer a comprehensive range, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Committed to reliable delivery and exceptional customer service, Yousef Steel provides top-grade materials that ensure superior performance across various industrial applications. Trust Yousef Steel for all your Carbon Steel EN 10083-2 Pipe needs.
| Execution | Size Range | OD Tolerance | Wall tolerance |
|---|---|---|---|
| Hot-rolled Tube | OD – 80 mmOD > 80 mmWall < 12 mmWall – 12 mm | ± 0.4 mm± 0.5 % of OD | ± 0.7 mm± (5 % x wallthickness + 0.1 mm |
| Hot-rolled peeled tube | All sizesWall < 12 mmWall – 12 mm | + 0.25/- 0 mm | ± 0.8 mm± (5 % x wall thickness+ 0.2 mm) |
| Cold Worked tubecold-rolled or cold-drawn | OD < 40 mmOD 40 – 80 mmOD > 80 Wall Thickness < 6 mm Wall Thickness6 – 8 mm Wall Thickness > 8 | + 0.30/- 0 mm*+ 0.35/- 0 mm*+ 0.40/- 0 mm* | ± 0.30 mm± 0.35 mm± 0.40 mm |
These Carbon Steel EN 10083-2 Grade C22R Pipes are commonly utilized in applications that demand good machinability, ductility, and moderate strength. Typical uses include automotive components such as bushings, connecting rods, and low-stress shafts. In general engineering, they find applications in pins, studs, fasteners, and structural parts that benefit from surface hardening. Additionally, these pipes are ideal for agricultural equipment and machinery parts that require easy fabrication and moderate load-bearing capacity. Thanks to their ability to undergo carburizing, C22R pipes can develop a hard outer layer while maintaining a tough core, making them suitable for components that face friction and wear.
