Yousef Steel is a reputable manufacturer and supplier of Carbon Steel EN-24 Bars, proudly based in Riyadh, Saudi Arabia. Known for its unwavering dedication to quality and precision, Yousef Steel delivers high-performance EN-24 bars that are perfect for demanding industrial applications. These bars stand out for their exceptional strength, toughness, and impressive fatigue resistance, making them a go-to choice for heavy-duty mechanical components. Catering to vital sectors like automotive, aerospace, power generation, and general engineering, Yousef Steel guarantees that all EN-24 bars are crafted to meet international standards, providing clients with durable and reliable solutions, along with timely delivery and outstanding customer support throughout the region.
Carbon Steel EN-24 Bars are crafted from a nickel-chromium-molybdenum alloy steel, featuring around 0.36–0.44% carbon, 1.3–1.7% nickel, 0.45–0.65% chromium, and 0.2–0.35% molybdenum. This unique blend results in remarkable strength, toughness, and wear resistance. Typically, EN-24 bars showcase a tensile strength ranging from 850 to 1000 MPa and a yield strength of about 680 MPa. The Brinell hardness falls between 248 and 302 HB. These bars are often supplied in hardened and tempered conditions, which boosts their mechanical properties for use in critical and high-stress industrial applications.
| Grade | EN24 |
|---|---|
| Specification | BS970 1.0904 55Si7 55S6 55Si2Mn ASTM 9255 |
| Round bar size | Diameter: 3-~800mm |
| Hex Bar size | 2-100mm A/F |
| Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Square bar size | 4 to 100mm |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Section | 3.0 to 12.0mm thickness |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Billet Size | 1/2″ to 495mm Diameter |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Finish | Cold (bright) drawn, centreless ground,smooth turned, peeled, slit rolled edge, hot rolled, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Condition | Hardened & tempered, annealed |
| Technique | EN45 Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Processing | Bar cutting to 650mm |
| Form | EN45 Welding Rod, Round, Rod, T-Bar, Channel Bar, Precision Ground Bar, Flat Bar, Square, Blocks, Round Rod, Rings, Hollow, Triangle, Rectangle, Hex (A/F), Threaded, Half Round Bar, Profiles, Billet, Ingot, I/H Bar, Forging etc. |
| Element | En42J |
| C | 0.75 – 0.90% |
| Mn | 0.50 – 0.90% |
| Si | 0/1 – 0.35 |
| S | 0.04% Max |
| P | 0.04% Max |
817M40T / EN24T Steel Mechanical Properties | ||||||
|---|---|---|---|---|---|---|
Size | Tensile | Yield | Elongation | Impact | Impact | Hardness |
63 to 150 | 850-1000 | 680 Min | 13% | 54 | 50 | 248/302 |
150 to 250 | 850-1000 | 654 Min | 13% | 40 | 35 | 248/302 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
Carbon Steel EN-24 Bars find extensive use in scenarios that demand high tensile strength, shock resistance, and fatigue endurance. They are particularly well-suited for manufacturing automotive components like gears, shafts, crankshafts, axles, and drive shafts. In the aerospace and defense industries, they serve as structural components and high-load-bearing parts. EN-24 bars are also employed in heavy machinery, marine equipment, power generation turbines, and tooling systems. Their excellent machinability and ability to retain strength under dynamic loads make them ideal for components that face constant mechanical stress and challenging operating conditions.
